| Item NO. | Compare | Net Weight | Gate Feature | Body | Gate Strength | 100% proof loaded | Min. Breaking load | Meets | Color | Body | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| g | Twist Locking | TripleLocking | Captive Pin | 3600 Lbs Gate Strength | ANSI Z359.12-2019 | CSA Z259.12-16 | EN 362 : 2004 | ||||||
| N-268G-S | Compare | 254 | ✔ | - | - | ✔ | 3600 lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Polished | Stainless steel, SUS 420 |
| N-268G-CP-S | Compare | 254 | ✔ | - | ✔ | ✔ | 3600 lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Polished | Stainless steel, SUS 420 |
| N-268G-TRCP-S | Compare | 254 | - | ✔ | ✔ | ✔ | 3600 lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Polished | Stainless steel, SUS 420 |
| Item NO. | Compare | Net Weight | Gate Feature | Body | Gate Strength | 100% proof loaded | Min. Breaking load | Meets | Color | Body | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| oz. | Twist Locking | TripleLocking | Captive Pin | 3600 Lbs Gate Strength | ANSI Z359.12-2019 | CSA Z259.12-16 | EN 362 : 2004 | ||||||
| N-268G-S | Compare | 8.9 | ✔ | - | - | ✔ | 3600 lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Polished | Stainless steel, SUS 420 |
| N-268G-CP-S | Compare | 8.9 | ✔ | - | ✔ | ✔ | 3600 lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Polished | Stainless steel, SUS 420 |
| N-268G-TRCP-S | Compare | 8.9 | - | ✔ | ✔ | ✔ | 3600 lbs / 16 kN | 5000 lbs / 23 kN | ✔ | ✔ | ✔ | Polished | Stainless steel, SUS 420 |
